5-103168-3 TE Connectivity | PCBX Electronics

5-103168-3

Manufacturer:

TE Connectivity

Mfr.Part #:

5-103168-3

Datasheet:

Description:

Headers and Wire Housings Through Hole Header, Pin, Plug Number of Positions:10 Pitch:2.54 mm

Parameter	Value
Voltage Rating (DC)	250 V
Length	15.54 mm
Width	15.5448 mm
Termination	Solder, Through Hole
Max Operating Temperature	105 °C
Min Operating Temperature	-65 °C
Voltage Rating (AC)	250 V
Height	6.98 mm
Packaging	Tray
Depth	10.16 mm
Lead Free	Lead Free
RoHS	Compliant
Lead Pitch	2.54 mm
Insulation Resistance	5 GΩ
REACH SVHC	No SVHC
Contact Plating	Gold
Lead Length	3.175 mm
Contact Material(Contact Finish)	Bronze
Pitch	2.54 mm
Current Rating	3 A
Flammability Rating	UL94 V-0
Approvals	CSA
Orientation	Vertical
Lifecycle Status	Production (Last Updated: 1 week ago)
Color	Black
Gender	Male
Number of Contacts	10
Connector Type	Header, Pin, Plug
Number of Positions	10
Number of Rows	2
Row Spacing	2.54 mm
Housing Material	Thermoplastic
Fastening Type	Detent
Contact Style	Pin
Contact Resistance	15 mΩ
Contact Current Rating	3 A
Housing Color	Black
Contact Mating Length	8.0772 mm
Keyed	No
PCB Mounting Orientation	Vertical
PCB Thickness	1.397 mm
Contact Gender	Male
High Temperature Housing	No
Mating Post Length	8.08 mm
Contact Shape	Square
Shrouded End Dimension	1.68 mm
High Speed Serial Data Connector	No
Manufacturer Lifecycle Status	ACTIVE (Last Updated: 1 week ago)
Termination Post Length	3.18 mm
